Our company, with over 31 years of industry leadership and a team of 46 seasoned experts, proudly introduces the AC Axial Fan 8038—a premium cooling solution designed for demanding industrial and commercial applications. Backed by 36 patent qualifications and 12 invention patents, and certified under ISO-9001, ISO-14001, UL, CE, TUV, and RoHS2.0 standards, our AC Axial Fan 8038 exemplifies innovation, quality, and reliability that meet the evolving needs of global customers.
AC Axial Fan 8038: Product Overview
The AC Axial Fan 8038 measures 80mm x 80mm x 38mm, featuring a robust shaded pole motor and a die-cast aluminum frame that ensures durability and excellent heat dissipation. The impeller is crafted from PBT (Polybutylene Terephthalate) reinforced with 30% fiberglass, providing exceptional mechanical strength and flame retardance (UL94V-0 rating). This combination of materials guarantees the fan withstands harsh environments while delivering consistent performance.
Equipped with high-precision ball or oil-retaining sleeve bearings, the AC Axial Fan 8038 offers long operational life—up to 50,000 hours for ball bearings and 20,000 hours for sleeve bearings—while maintaining low noise levels between 28 to 35 dBA depending on the model variant. Operating at voltages of 100-240V AC and frequencies of 50/60 Hz, it delivers airflow rates ranging from approximately 0.49 to 0.62 cubic meters per minute (m³/min) at speeds of 2300 to 2600 RPM. Its IP54 protection rating ensures resistance to dust and water splashes, making it suitable for diverse industrial settings.
Materials and Advantages
Frame: High-grade die-cast aluminum alloy offers superior structural strength, corrosion resistance, and enhanced thermal conductivity, which helps dissipate heat efficiently.
Impeller: Injection-molded PBT with 30% fiberglass reinforcement ensures rigidity and dimensional stability, reducing vibration and noise during operation.
Bearings: Choice of ball or oil-retaining sleeve bearings allows customers to select between longer lifespan or cost-effective solutions, both designed for smooth, quiet operation.
Safety and Compliance: Flame-retardant materials and robust insulation meet UL, CE, and RoHS2.0 standards, ensuring user safety and environmental compliance.
These material choices and manufacturing precision translate into a fan that is not only reliable but also energy-efficient and low maintenance, ideal for continuous operation in critical applications.
Production Process Highlights
Our AC Axial Fan 8038 is manufactured through a meticulous process emphasizing quality at every stage:
Die-Casting and Machining: The aluminum frame is die-cast and precision-machined to exact dimensions, ensuring a perfect fit and structural integrity.
Impeller Injection Molding: The fan blades are formed in a single injection molding process using PBT reinforced with fiberglass, providing uniform strength and flame retardance.
Motor Assembly: The shaded pole motor is assembled with impedance protection and insulated windings to withstand heat and electrical stress.
Bearing Installation: High-quality bearings are installed under strict cleanliness and lubrication standards to maximize lifespan and reduce noise.
Final Assembly and Testing: Each fan undergoes rigorous electrical, airflow, noise, and durability testing to ensure compliance with ISO-9001 quality management and international safety certifications.
Packaging: Fans are carefully packaged with protective guards and mounting hardware, ready for wholesale distribution.
Applications in Exposure Units and Beauty Instruments
The AC Axial Fan 8038 is widely adopted in specialized equipment such as exposure units (晒板机) and beauty instruments, where precise and reliable cooling is essential.
Exposure Units: These machines require stable temperature control to ensure accurate photoresist exposure during PCB manufacturing or printing plate preparation. The 8038 fan provides consistent airflow to dissipate heat generated by UV lamps and electronic components, enhancing process stability and prolonging equipment life.
Beauty Instruments: Devices such as facial steamers, laser therapy machines, and other skincare equipment generate heat during operation. The AC Axial Fan 8038 efficiently cools internal electronics and mechanical parts, ensuring safe operation and maintaining device performance without adding excessive noise that could disrupt the user experience.
The fan’s compact size, robust materials, and long service life make it an ideal cooling solution in these precision-driven fields.
Why Choose Our AC Axial Fan Factory for Wholesale?
As a leading AC Axial Fan Factory with over three decades of expertise, we offer the AC Axial Fan 8038 at competitive wholesale pricing, supported by:
Comprehensive Quality Assurance: Our fans meet strict international standards (ISO-9001, UL, CE, RoHS2.0), guaranteeing reliability and safety.
Customizable Options: We provide OEM/ODM services including customized wiring, connectors, and branding to fit your specific application needs.
Technical Expertise: Our team of 46 professionals with 20+ years of experience offers dedicated support from product selection to after-sales service.
Efficient Production and Delivery: Streamlined manufacturing processes ensure timely order fulfillment without compromising quality.
Sustainable Practices: Our adherence to ISO-14001 environmental management reflects our commitment to eco-friendly manufacturing.
By sourcing your cooling solutions from our AC Axial Fan Factory, you gain access to a trusted partner capable of delivering high-quality, innovative fans designed to enhance the performance and longevity of your equipment.
Hot tags: AC Axial Fan 8038, 8038 AC Axial Fan, 80x80x38 ac axial fan, ac cooling ac axial fan, axial flow ac axial fan, China, OEM, customized, wholesale, discount, factory, manufacturers, suppliers
